MC33178 Dual Op Amp SMT Kit (#2811)
This is the popular MC33178 Dual Op Amp SMT IC Design Kit. It includes 6 pieces of the MC33178, Single-Supply, Dual Op Amp in the SMT SOIC-8 package. The MC33178 has 2 individual Op Amps with great specs. It has 600 Ohm Drive capability, large output voltage swing and a very good THD of 0.0024% @ 1.0KHz with 600 Ohm load and a high bandwidth of 5 MHz.! This excellent Op Amp has been around for years and is used in many professional audio circuits.
You also get 22 different values of SMT Resistors, different values of SMT Ceramic Capacitors, SMT Tantalum Capacitors, SMT Trimpots, SMT Diodes, and SMT LEDs
With these parts, you can make numerous circuits, such as active filters, pre-amps, signal conditioners, function generators and much more. Surface Mount Technology (SMT) parts do not have long leads; this is a chance to get some SMT parts and learn to use them. Search the web for incredible circuits to build. We supply the parts, you supply the ingenuity. You get the following:
| Type | Part Description | Quantity |
| SMT IC, SOIC-8 | MC33178, Dual Op Amp, Low Power | 6 ea |
| SMT Resistor | 1.2 Ohms, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 5.1 Ohms, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 8.2 Ohms, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 36 Ohms, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 100 Ohms, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 620 Ohms, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 1.0K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 2.0K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 10K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 12K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 15K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 20K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 27K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 33K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 47K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 56K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 82K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 100K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 150K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 200K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 270K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Resistor | 330K, 1/8 Watt, 5%, 1206 | 25 ea |
| SMT Capacitor | .001uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .0022uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .0047uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .01uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .033uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .047uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .068uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .1uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .22uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .33uF, 50v, X7R, 1206 | 10 ea |
| SMT Capacitor | .47uF, 25v, Case A, 20%, Solid Tantalum | 2 ea |
| SMT Capacitor | 1.0uF, 20v, Case B, 20%, Solid Tantalum | 2 ea |
| SMT Capacitor | 2.2uF, 6.3v, Case A, 20%, Solid Tantalum | 2 ea |
| SMT Capacitor | 3.3uF, 16v, Case B, 20%, Solid Tantalum | 2 ea |
| SMT Capacitor | 4.7uF, 10v, Case B, 20%, Solid Tantalum | 2 ea |
| SMT Diode | FMMD914, Silicon, Switching, SOT-23 | 10 ea |
| SMT Potentiometer | 20K, Single-Turn, Thru-Hole | 2 ea |
| SMT Potentiometer | 220K, Single-Turn, Thru-Hole | 2 ea |
| SMT Potentiometer | 1.0M, Single-Turn, Thru-Hole | 2 ea |
| SMT LED | Red, Clear Lens, 140° view, 0805 | 2 ea |
| SMT LED | Green, Clear Lens, 140° view, 0805 | 2 ea |
| SMT LED | Yellow, Clear Lens, 140° view, 0805 | 2 ea |
